TILARA® POLYCARBONATE COMPACT SHEET

TILARA Solid Polycarbonate Sheets offer a wide range of properties that make them superior to other thermoplastic sheets and the preferred material for high-performance roofing, glazing, and fabricated solutions.

Tilara Solid Polycarbonate Sheets excel in impact resistance, transparency, and temperature resistance, making them an ideal glazing material for industrial and commercial applications. They also boast excellent fire-retardant properties and are classified as self-extinguishing.

With exceptionally high impact resistance, Tilara Solid Polycarbonate Sheets are widely used for safety glazing and applications subject to high vibrations and accidental impacts, such as noise barriers along highways, visual and noise barriers on bridges, and security barriers. These sheets are 250 times stronger than glass and 25 times more impact-resistant than acrylic sheets.

Additionally, Tilara Solid Polycarbonate Sheets can be engineered for food-grade applications and to enhance fire-retardant properties for specific needs.

Tilara Embossed Polycarbonate Sheets: Tilara Embossed Polycarbonate Sheets offer all the advantages of solid polycarbonate sheets, with the added benefit of excellent light diffusion. This makes them ideal for skylights and profiled sheets used in tandem with metal, asbestos cement, GI, and other profiled roofing sheets for skylight and daylight cladding applications.

Tilara Diamond Polycarbonate Sheets: Featuring a diamond-like surface texture, Tilara Diamond Polycarbonate Sheets are available in attractive colors, making them perfect for decorative applications, residential roofing, and glazing structure coverings. Standard colors include clear, bronze, blue, lake blue, and green, with special colors available for large quantity requirements.

Tilara Solid and Embossed Polycarbonate Sheets are available in roll form for lower thicknesses and are extensively used for manufacturing profiled sheets and thermoformed/vacuum-formed products.

FEATURES

  • Very good thermal insulation
  • Excellent Transparency
  • UV Protected & Durable
  • Wide Temperature Resistance Range (-40°C to 120°C)
  • Fire Retardant (Self Extinguishing)
  • Good Sound Insulation at higher thickness
  • Light in weight
  • Easy to handle, carry and Install
  • Can be fabricated, cut & drilled with conventional tools
  • Environment Friendly (100% Recyclable)

RELATED INDUSTRIES

  • Building & Construction
  • Glazing & Fenestration
  • Machinery & OEM
  • Lighting & Illumination
  • Vacuum Forming
  • Defence & Security Glazing
  • Signage & Advertising
  • Railways, Aerospace & Surface Transport

TILARA® POLYCARBONATE SOLID SHEET

GENERAL
General Properties Method Units Value
Density ISO 1183 g.cm3 1.2
Light transmission (Depending on thickness) ASTM D 1003 % 81-90
Refractive Index ISO 489 1585
MECHANICAL
General Properties Method Units Value
Tensile Strength at yeild ISO 527-2 MPa 60
Tensile Modulus ISO 527-2 MPa 60
Elongation at break ISO 527-2 % >100
Elongation at yeild % 6
Flexural Modulus ISO 178 MPa 2330
Charpy Un-notched ISO 179 kJ/m2 NOt Break
Izod Impact notched ISO 180a kJ/m2 >65
THERMAL
General Properties Method Units Value
Temp of deflection(HDT) Under load of 1.8MPa ISO 75-1 °C 130
Vicat Softening temp (50°C/h 50N) ISO 306 °C 144
Thermal Conductivity DN52612 W/m x °C 0.2
Coefficient of linear thermal expansion 0-50°C ISO 11359 mm/(m x 1/°C) 0.070
GWFI(Glow-Wire Flammability index) IEC60695-2 °C 900
ELECTRICAL
General Properties Method Units Value
Volume Resistivity IES 60093 Ω x cm 3 X 1014
Surface Resistivity,dry IEC 60093 Ω 6 X 1015
Dissipation Factor 1Mhz IEC 60250 0.009
Dissipation Factor 100hz IEC 60250 0.0006

AVAILABLE IN

COLORS

Clear, Opal, Bronze, Green, Blue, Metallic Grey, Pencil Grey & Greenish Blue

DIMENSIONS

Width: up to 2100mm

Thickness: 1mm to 12mm

TYPE

Options: Embossed texture, Diamond texture, Matte texture, Single & Both sided UV Protection.

Specials: Special Transparent, translucent & opaque options are available on request.
